電離子切割機零件

EASB PT-600 和 PT-19XLS heavy duty
第 1 2 頁

	Reference number			產品概述	包裝數量
1	37081	N/A	N/A	Shield retainer, 銅	1
2	21795	0558006130	0004470027	Shield, 3.0 mm, 35–50A	1
3	0558006141	0558004678	N/A	Shield, 4.1 mm, 200A (PT-600 EPP Process)	1
	21802	0558006166	0004470028	Shield, 6.6 mm, 100–250A	1
	21945	0558006199	0004470029	Shield, 9.9 mm, 325–600A	1
	21796	N/A	0004470030	Diffuser, 50A	1
4	21944	N/A	0004470031	Diffuser, 100–600A	1
	22496	N/A	0004470115	Diffuser,100–600A, reverse	1
5	N/A	N/A	N/A	噴嘴 retaining cap, quick - change	1
6	37082	N/A	0004470045	噴嘴 retaining cap	1
7	N/A	0558001881	N/A	CoolFlow™ 噴嘴, 1.0 mm, 50A	1
	N/A	0558001882	N/A	CoolFlow 噴嘴, 1.8 mm, 100A	1
	N/A	0558001883	N/A	CoolFlow 噴嘴, 2.0 mm, 150–200A	1
	N/A	0558001884	N/A	CoolFlow 噴嘴, 2.3 mm, 200A	1
	21822	0558001623	N/A	CoolFlow 噴嘴, 2.5 mm, 250A	1
	35885	0558001885	N/A	CoolFlow 噴嘴, 3.0 mm, 360A	1
	22195	0558001886	N/A	CoolFlow 噴嘴, 3.6 mm, 400A	1
	22401	0558001887	N/A	CoolFlow 噴嘴, 4.1 mm, 600A	1
8	34086	0558004458	0004485684	SilverLine® 電極, 50–250A, PT-19XLS	1
9	35886	0558004460	0004485829	SilverLine 電極, 360A, PT-19XLS	1
10	0558004461	0558001624	N/A	SilverLine 電極, 250A, PT-600	1
11	0558004462	0558002516	N/A	SilverLine 電極, 360/400A, PT-600	1
